EVERBRITE SMD LED 5050

Name: EVERBRITE SMD LED 5050
Brand: TAURUS OPTO SEMICONDUCTORS LLP
Price: 10 INR
Availability: InStock

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 2000 Pieces

EVERBRITE SMD LED 5050 Specification

Light Color
Cool White

Current Rating
60mA (per chip)

Shape
Square

Life Span
50,000 Hours

Control Type
Pulse-width modulation (PWM)

Efficiency (%)
High (>90%)

Housing
Plastic Encapsulation

Response Time
<100 ns

Operating Temperature
-40C to +85C

Humidity %
40% - 90% RH

Power Supply
DC

Beam
120

Product Type
SMD LED

Material
Epoxy Resin & Copper

Base
Surface Mount

Power Factor
High

Input Voltage
3.0V (per chip)

Working Temperature
-40C to +85C

Lamp Power
0.2W - 0.24W per chip

Application
Lighting, Displays, Backlighting, Signage

Size
5050

Dimension (L*W*H)
5.0mm x 5.0mm x 1.6mm

Weight
Approx. 0.05g

Color
White

LED Type
5050 SMD

Color Temperature
6000-6500K

IP Rating
IP20

RoHS Compliant
Yes

CRI (Color Rendering Index)
>80

Reflow Soldering Capability
Yes

Lead-free
Yes

Wavelength
NA (White LED)

Chromaticity
Consistent

Luminous Intensity
20003000 mcd

Mounting Type
SMD (Surface Mount Device)

ESD Protection
Class 2

Storage Temperature
-40C to +100C

EVERBRITE SMD LED 5050 Trade Information

Minimum Order Quantity
2000 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
10000 Pieces Per Day

Delivery Time
5 Days

Main Domestic Market
All India, South India, Central India

About EVERBRITE SMD LED 5050

SMD LED" stands for "Surface Mount Device Light Emitting Diode." These are LEDs (Light Emitting Diodes) that are designed to be mounted directly onto the surface of a printed circuit board (PCB) or other substrate. Unlike through-hole LEDs, which have leads that are inserted into holes on the PCB and soldered on the other side, SMD LEDs have flat contacts that can be soldered directly onto the PCB surface.

SMD LEDs come in various sizes and shapes, such as 3528, 5050, and 2835, with the numbers denoting their dimensions in metric units (in this case, 3.5mm x 2.8mm, 5.0mm x 5.0mm, and 2.8mm x 3.5mm, respectively). They are widely used in many applications including backlighting for LCD displays, indicator lights, automotive lighting, decorative lighting, and general illumination.

SMD LEDs offer advantages such as smaller size, easier automated assembly (especially with pick-and-place machines), and the ability to create thinner devices compared to through-hole LEDs. They are commonly used in modern electronics due to their versatility and efficiency.

High-Efficiency Illumination

EVERBRITE SMD LED 5050 provides brilliant illumination with high luminous efficiency and consistent color rendering. Its cool white light output is engineered for clarity and visual comfort, making it a superb choice for demanding lighting and display projects. Built with durable materials, it ensures reliability across a variety of uses.

Built for Endurance and Versatility

Designed for challenging environments, this SMD LED operates efficiently between -40C and +85C. Its robust epoxy resin and copper construction, combined with plastic encapsulation, provide longevity and resistance to humidity up to 90% RH. The LED is perfect for applications requiring reliable and stable performance over long periods.

Simple Integration and Compliance

With its SMD base, the 5050 LED is easily integrated using standard reflow soldering processes. It is RoHS compliant and lead-free, making it environmentally friendly and safe for manufacturing. Its compact square design and high power factor ensure seamless addition to PCBs and electronic modules.

FAQ's of EVERBRITE SMD LED 5050:

Q: How do I mount the EVERBRITE SMD LED 5050 to my circuit board?

A: The EVERBRITE SMD LED 5050 is designed for surface mount applications and is compatible with standard reflow soldering processes. Ensure the board and component are properly positioned and follow recommended reflow soldering profiles for secure attachment.

Q: What are the benefits of using the EVERBRITE SMD LED 5050 in lighting projects?

A: This LED offers high luminous intensity, energy efficiency (>90%), consistent color chromaticity, and a high color rendering index (>80). It also provides a long operational life of up to 50,000 hours, ensuring reliable, vivid, and maintenance-free illumination over time.

Q: When should I use a cool white LED with a color temperature of 6000-6500K?

A: Cool white LEDs, such as the EVERBRITE 5050, are ideal for applications that require bright, clear light, such as general lighting, display cases, commercial signage, and backlighting where visual precision is important.

Q: What type of power supply and current is suitable for this LED?

A: Each 5050 SMD LED chip operates at 3.0V DC with a current rating of 60mA and a power range of 0.2W-0.24W per chip. Ensure your power supply matches these requirements to maintain performance and longevity.

Q: Where can the EVERBRITE SMD LED 5050 be effectively used?

A: This LED is suited for indoor applications such as lighting fixtures, display panels, advertising signage, and electronics backlighting. Its IP20 rating makes it suitable for protected environments rather than direct outdoor or wet locations.

Q: How does ESD protection and RoHS compliance benefit the product and the user?

A: Class 2 ESD protection safeguards the LED from electrostatic discharge during handling and installation, reducing failure rates. RoHS compliance and lead-free construction make it safe for the environment and end-users, meeting global regulatory standards.

Q: What is the recommended storage temperature and environment for these LEDs?

A: To preserve quality, store the EVERBRITE SMD LED 5050 in a humidity-controlled environment (40%-90% RH) at temperatures between -40C and +100C. This helps maintain performance and prevents damage prior to assembly.
