COB CHIP 1311

Name: COB CHIP 1311
Brand: TAURUS OPTO SEMICONDUCTORS LLP
Price: 10 INR
Availability: InStock

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 5000 Plants

COB CHIP 1311 Specification

Housing
No housing (bare chip)

Power Supply
Constant Current Driver

Humidity %
10% to 90% RH (non-condensing)

Response Time
<1 ms

Current Rating
280mA

Shape
Rectangular

Light Color
Warm White / Cool White / Neutral White

Life Span
50,000 hours

Efficiency (%)
>125 lm/W

Control Type
Direct Drive (Non-dimmable)

Beam
120

Operating Temperature
-20C ~ +60C

Product Type
COB LED Chip

Material
Ceramic base with silicone encapsulation

Base
SMD Surface Mount

Power Factor
>0.9

Input Voltage
36V

Working Temperature
-20C to +60C

Lamp Power
10W

Application
LED lighting, Downlights, Panel lights, Spotlights

Size
1311 (13x11mm module)

Dimension (L*W*H)
13 mm x 11 mm x 1.2 mm

Weight
1.2 g

Color
White

LED Type
Chip On Board (COB)

Color Temperature
3000K / 4000K / 6000K

IP Rating
IP20

CRI (Color Rendering Index)
>80

ESD Protection
>2000V

Storage Temperature
-40°C to +80°C

Luminous Flux
1250-1350 lm

Package
Tray

Chip Brand
Epistar / Sanan options available

Thermal Resistance
<3.5°C/W

COB CHIP 1311 Trade Information

Minimum Order Quantity
5000 Plants

Supply Ability
10000 Plants Per Day

Delivery Time
5 Days

Main Domestic Market
All India

About COB CHIP 1311

"COB chip" likely refers to "Chip-on-Board" technology. In this context, it refers to a method of semiconductor packaging where the bare semiconductor chip is directly mounted onto a printed circuit board (PCB) or substrate. This packaging technique offers advantages such as compact size, improved thermal performance, and potentially lower cost compared to traditional packaging methods where the chip is encapsulated in a separate package. COB chips are commonly used in various applications including LED lighting, automotive electronics, and consumer electronics.

Superior Performance and Longevity

The COB CHIP 1311 delivers impressive luminous output and energy efficiency. Designed with a high-quality ceramic base and silicone encapsulation, it offers excellent heat dissipation and resilience for continuous operation. Its 50,000-hour life span and robust ESD protection make it a reliable choice for both commercial and residential lighting setups.

Versatile Lighting Applications

Created for flexibility, the COB CHIP 1311 supports a range of color temperatures-3000K, 4000K, and 6000K-suiting warm, neutral, or cool white lighting requirements. The compact 13x11mm design easily integrates into downlights, panel lights, and spotlights, allowing designers and installers to use it in multiple environments efficiently.

FAQ's of COB CHIP 1311:

Q: How do I properly mount and connect the COB CHIP 1311 for optimal performance?

A: The COB CHIP 1311 is designed for SMD surface mounting on compatible PCBs. Use a constant current driver set to 280mA and 36V input. Ensure good thermal contact with your fixture and allow space for adequate airflow to maximize the chip's thermal management.

Q: What is the recommended process for storing and handling the COB CHIP 1311?

A: Store the chip between -40C and +80C in a low-humidity environment (10% to 90% RH, non-condensing). Handle the chip with ESD precautions and avoid direct touch on the chip surface to maintain its integrity.

Q: When should I choose the COB CHIP 1311 over other LED modules?

A: Opt for COB CHIP 1311 when you need high luminous efficiency, a reliable CRI (>80), a wide color temperature range, and long operational life. It is ideal for applications that require consistent brightness and color accuracy, such as downlights and spotlights.

Q: Where can the COB CHIP 1311 be used?

A: This chip is suitable for indoor installations, such as LED lighting, downlights, panel lights, and spotlights. Its IP20 rating means it should be used in dry, dust-free conditions and not in outdoor or wet environments.

Q: What are the benefits of choosing the COB CHIP 1311 for lighting projects?

A: It offers high energy efficiency (>125 lm/W), excellent color rendering, rapid response time (<1 ms), and robust ESD protection, ensuring long-term reliability. Its compact design and wide beam angle (120) provide versatile and consistent illumination in various lighting setups.

Q: Can the COB CHIP 1311 be used with dimmable drivers?

A: The COB CHIP 1311 is designed for direct drive with a constant current supply and is non-dimmable. Use it only with compatible, non-dimming constant current drivers to avoid performance issues.
